Signals¶

Signals (workflow vocabulary) and their step-local cousins (step inputs and step outputs) are how named values flow through a validation run. They let workflow authors write assertions that reference data by name rather than by hard-coded paths.

This doc explains the mental model, the CEL context structure, the underlying Django models, and the runtime flow. For a worked example, see Signals Tutorial Example. For the user-facing CEL reference, see CEL Expressions.

The mental model¶

Validibot organizes named values into five places in a CEL assertion's context, distinguished by scope (workflow-wide vs. step-local) and by authorship (who picks the name).

                Workflow vocabulary  (s.*)           module scope
                       ▲              ▲
                       │ promote      │ promote
                       │              │
            Step inputs (i.*)    Step outputs (o.*)  function scope
                   ▲                    ▲
                   │                    │
            parser facts          container output
            resolved bindings     derived signals
            template variables

p.* sits to the side as "the raw submission" — always present, not in any scope hierarchy because it isn't named.

The teaching analogy worth keeping in mind: each step is a function. Inputs (i.*) are its parameters. Outputs (o.*) are what it returns. The workflow vocabulary (s.*) is module-level state shared across functions. Any function-local value can be promoted into module state via "Copy to Signal" — works for inputs and outputs symmetrically.

When do step inputs and step outputs exist?¶

A natural question once you've learned the namespaces is: "Why are i.* and o.* sometimes empty?" The answer is precise enough to be a test:

A step populates i.* or o.* only when it runs a process that transforms data. If the validator just checks structural rules over the payload, both namespaces stay empty — the assertion author works entirely with p.* and s.*.

Validibot's validators occupy three positions on this spectrum.

Position 1: no process — only p.* and s.* apply¶

Validators that check structural rules over the submitted payload without transforming it. The payload IS the data; there's no derived view to expose.

• JSON Schema — validates JSON against a JSON Schema document
• XML Schema — validates XML against an XSD
• Basic — applies CEL or comparison rules over the payload directly

For these, both i.* and o.* are empty. Results emerge as findings, not as named values to assert against.

Position 2: process produces outputs — only o.* populated¶

Validators that parse or evaluate a structured payload and emit results as named values. No separate pre-execution input stage — the parser IS the work.

• SHACL — parses RDF, runs shape constraints, emits violation counts and namespace flags
• THERM — parses THMX XML and emits 14 facts (polygon count, mesh level, BC temperatures, etc.)

For these, i.* is empty; o.* is the author's primary surface.

Position 3: process has discrete input and output stages — both i.* and o.* populated¶

Validators that translate an arcane payload format into named facts before doing their main work, then produce computed results after.

• EnergyPlus — parses IDF into facts (i.zone_count, i.idf_version), runs simulation, emits metrics (o.site_eui_kwh_m2, o.unmet_hours)
• FMU — resolves model input variables (i.setpoint_temp), runs simulation, emits results (o.T_room, o.Q_cooling_actual)

For these, both namespaces are meaningful at the appropriate stages.

The bright-line test¶

"Does this validator have a process that transforms data?" is a yes/no question with a clear answer per validator. That's what makes the spectrum precise rather than fuzzy. The corresponding empty-state UX messages in the step UI's Inputs/Outputs panels honestly tell authors why each panel is or isn't populated for the validator they're using.

Four concepts at the data layer¶

The model distinguishes four kinds of named values:

1. Workflow signals — WorkflowSignalMapping (the s.* namespace)¶

Author-defined values mapped to paths in the submission payload. Resolved once before any step runs; visible to every step.

• Created by the workflow author via the "Edit Signals" UI on the workflow page
• Each mapping has a name (the CEL identifier) and a source path (a dotted/bracket path into the submission data)
• Available as s.<name> in every step

2. Step inputs — StepIODefinition with direction=INPUT (the i.* namespace)¶

Step-local values the validator has at the start of a step, before its container or main work runs. Three sources feed i.*:

• Parser-extracted facts — values the validator extracts from the submission payload (or stamped metadata) via its extract_input_signals() hook (e.g. EnergyPlus parses the IDF and exposes i.zone_count, i.idf_version; FMU reads stamped introspection_metadata and exposes i.fmi_version, i.input_variable_count). Source for arcane-format validators that ship a parser.
• Resolved StepInputBindings — values resolved from author-configured bindings before the container runs. FMU's model input variables are the canonical example: the .fmu file declares its inputs; the author binds each to a payload path or signal; the launcher resolves them and places the values in i.*. EnergyPlus template variables work the same way.
• Catalog-declared inputs with no binding — declared in the validator catalog but with on_missing = "null" so they default to null when not resolved. Rare in practice; appears mostly during catalog evolution.

i.* values are step-local. i.zone_count in one step has no relationship to i.zone_count in another step (different submissions, different parses). For workflow-wide access, promote the input to a signal.

3. Step outputs — StepIODefinition with direction=OUTPUT (the o.* namespace)¶

Step-local values the validator produces after running. The catalog declares the contract (slug, type, description); extract_output_signals() populates the values from the container's output envelope.

o.* values are temporally bound — only available in output-stage assertions on the producing step. An input-stage assertion that references o.* resolves to null at runtime. Strict edit-time rejection is partially implemented (the autocomplete supports a stage filter, and CEL classifier recognizes i.* references); threading the stage parameter through every view call site to enforce strict rejection at submit time is planned follow-up work tracked in ADR-2026-05-22.

4. Promoted signals (the bridge between i.*/o.* and s.*)¶

Any step-local input/output definition — input or output — can be promoted into the workflow vocabulary under a workflow-wide name. The promotion is stored in one of two places depending on who owns the row:

• Step-owned StepIODefinition rows carry the name in their in-row promoted_signal_name field. One owner, no scope ambiguity.
• Validator-owned rows (shared catalog entries like the EnergyPlus outputs) are promoted via a WorkflowStepIOPromotion overlay row keyed on (workflow_step, signal_definition). The overlay exists because a single in-row value can't carry a different name per workflow; overlay rows pointing at step-owned definitions are rejected by clean() so a value never appears under two s.* aliases.

After promotion:

• The original i.<contract_key> or o.<contract_key> still exists (step-local, validator-named)
• A new s.<promoted_signal_name> exists (workflow-wide, author-named)
• Both resolve to the same underlying value

Promotion is the explicit ceremony for "lift this from step-local to workflow-wide." Authors trigger it via the "Copy to Signal" control on the inputs or outputs table — the storage split is invisible to them.

Summary table¶

The CEL context structure¶

Every CEL expression evaluates against a context with six namespaces (four with long-form aliases). The context is built by _build_cel_context() in validibot/validations/validators/base/base.py. The legal root names are defined once in CEL_NAMESPACE_ROOTS (validibot/validations/cel.py), from which every authoring-time allowlist derives — see "One source of truth" below.

context = {
    "p": payload,            # alias for payload
    "payload": payload,      # raw submission or validator output data
    "s": signals_dict,       # alias for signal
    "signal": signals_dict,  # workflow signals + promoted values
    "i": inputs_dict,        # alias for input
    "input": inputs_dict,    # parser facts + resolved bindings (this step)
    "o": output_dict,        # alias for output
    "output": output_dict,   # this step's declared output signals
    "steps": steps_context,  # inputs and outputs from completed upstream steps
    "submission": submission_dict,  # submission envelope (metadata + facts)
}

p / payload — raw submission data¶

Always present. Contains the raw submission payload (for input-stage assertions) or the validator's output envelope (for output-stage assertions). Authors access raw fields via dotted notation: p.building.envelope.wall_r_value or payload.results[0].value.

s / signal — workflow vocabulary¶

Contains the merged workflow-wide signal namespace, built from two sources:

1. Workflow-level signals from RunContext.workflow_signals (resolved from WorkflowSignalMapping rows before any step runs)
2. Promoted values injected by _inject_promotions() after the producing step completes — gathered from step-owned StepIODefinition rows with non-empty promoted_signal_name and from WorkflowStepIOPromotion overlay rows on validator-owned definitions; works for both input and output promotions

Workflow signals take precedence over promoted values if there's a name collision (workflow-defined names are the more stable identifier; the collision suggests the author meant to refer to the workflow mapping).

Authors access signals via s.target_eui or signal.target_eui.

i / input — step-local input values¶

Populated when this step begins, before its container runs (or before its main in-process work for built-in validators). Three sources:

1. Parser-extracted facts from the validator's extract_input_signals(payload) instance method. Validators that understand an arcane format implement this to expose useful facts about the submission before doing their main work. EnergyPlus extracts IDF facts; FMU exposes modelDescription.xml metadata stamped at upload/probe time via FMUModel.introspection_metadata (Phase 6 per ADR-2026-05-22b).
2. Resolved StepInputBinding values for inputs declared with direction=INPUT and bound to a payload path or signal. The launcher resolves each binding against the submission data before invoking the container. These are also merged into the contract-keyed i.* namespace at input stage so input-stage assertions can reference them alongside parser-extracted facts.
3. Catalog defaults for declared inputs that have neither a parser value nor a resolved binding — typically null with on_missing="null".

i.* is step-local. Different steps using the same validator on different payloads get different i.* values; references don't cross step boundaries.

Authors access input values via i.zone_count or input.zone_count.

o / output — step output values¶

Populated after the validator runs. For output-stage assertions, this contains the extracted output dict produced by extract_output_signals(). For input-stage assertions, o.* is empty (or null-defaulted) — the container hasn't run yet.

Authors access output values via o.site_eui_kwh_m2 or output.site_eui_kwh_m2. The autocomplete supports a stage filter that can hide this step's o.* from input-stage editors; strict form-level rejection of o.* references in input-stage assertions at submit time is partially implemented and planned to land via a follow-up. Until then, o.* references in input-stage assertions silently resolve to null at runtime rather than being caught at edit time.

steps — cross-step inputs and outputs¶

Contains both inputs and outputs from completed upstream steps. Each entry is keyed by the step's step_key and contains input and output sub-dicts:

{
  "preflight": {
    "input": { "idf_version": "25.1", "zone_count": 12 },
    "output": { "warning_count": 3, "fatal_count": 0 }
  },
  "energyplus_step": {
    "input": { "idf_version": "25.1", "zone_count": 12 },
    "output": { "site_eui_kwh_m2": 75.2 }
  }
}

Authors access cross-step values via steps.preflight.output.warning_count or steps.preflight.input.zone_count.

submission — the submission envelope¶

The sixth namespace (ADR-2026-06-03b). It carries context that lives beside the file rather than inside it — submitter-supplied metadata plus server-stamped facts — so it resolves identically for any submitted format, including non-JSON RDF .ttl/SHACL where p.* and s.* are barely populated. It is long-only: there is no single-letter alias because s already means signal.

It is assembled by a single shared builder, build_submission_assertion_context(validation_run) in validibot/validations/services/submission_context.py, which both the CEL context (context["submission"]) and the basic-assertion payload (payload["submission"], a nested sub-dict) consume — so the two engines see byte-identical data. A null run/submission yields {} (never raises), and every exposed field survives Submission.purge_content(), so the namespace is stable after the file bytes are gone.

Trust is per field, not inferred from nesting:

No duplication. The file's contents stay at the single canonical address p/payload; there is deliberately no submission.payload. The guiding rule for the whole namespace set: it does not become confusing because it is large, only when two prefixes can reach the same value — so guard against overlap, not against count.

Relationship to the SUBMISSION_METADATA binding scope. Both read Submission.metadata, but they serve different actors. submission.metadata.<key> is the general-purpose, rule-author-facing reader used in assertions. The BindingSourceScope.SUBMISSION_METADATA scope is the validator's way to consume a specific metadata field as a typed, declared i.<name> input (e.g. EnergyPlus's expected_floor_area_m2). They coexist as complementary layers; the signal-binding form does not treat a submission. prefix as a binding source, by design.

CEL expression examples¶

# Workflow signal (mapped from submission data)
s.target_eui < 100

# Promoted output from a prior step
s.simulated_eui < s.target_eui

# This step's input (parser-extracted IDF fact)
i.zone_count >= 4 && i.idf_version.startsWith("25.")

# This step's output (only in output-stage assertions)
o.site_eui_kwh_m2 < s.target_eui

# Compare input against output (cross-stage, in an output-stage assertion)
abs(i.expected_floor_area - o.floor_area_m2) < 5.0

# Raw payload access
p.building.envelope.wall_r_value > 10

# Cross-step output
steps.energyplus_step.output.site_eui_kwh_m2 < 100

# Cross-step input (e.g., reusing a parser fact from an earlier step)
steps.preflight.input.zone_count == steps.energyplus_step.input.zone_count

# Null guard for optional signals
s.max_unmet_hours != null && o.unmet_hours < s.max_unmet_hours

Stage-aware assertion authoring¶

An assertion's stage (input vs. output) determines which namespaces are available in CEL. The assertion form (RulesetAssertionForm in validibot/validations/forms.py) enforces this at edit time.

The autocomplete in the assertion-target widget is also filtered by stage — the variable picker for an input-stage assertion does not offer o.* entries, so authors aren't tempted by references that would silently resolve to null.

The check is performed by get_catalog_choices() in validibot/workflows/mixins.py, which takes a stage parameter and returns the right subset.

Model: WorkflowSignalMapping¶

File: validibot/workflows/models.py

Defines a workflow-level signal — an author's named vocabulary entry for a data point in the submission payload. Each row maps a signal name to a source path. Resolved once before any step runs; available to every step.

Fields¶

Constraints¶

• unique_signal_name_per_workflow: One signal name per workflow, enforced at the database level.

on_missing behavior¶

• error (default): The validation run fails immediately with a clear error message before any step is attempted.
• null: The signal is injected as null. The author must guard with s.name != null in CEL expressions. Accessing a null signal without a guard produces a fail-fast evaluation error with guidance on how to fix it.

Example¶

A workflow that validates energy models might define:

All three signals become available as s.target_eui, s.building_type, and s.floor_area in every step's CEL expressions.

Model: StepIODefinition¶

File: validibot/validations/models.py

The stable data contract for a named step input or step output at the validator or step level. A StepIODefinition declares that a validator or workflow step expects (input, i.*) or produces (output, o.*) a named data point with a specific type. It is the "what" — the contract — not the "where" (that is the binding, StepInputBinding).

This model was previously named SignalDefinition. The rename landed with ADR-2026-05-22b (internal); the database table (validations_signaldefinition) was kept stable to avoid a destructive rename across mature data.

This model unifies step input/output metadata that was previously scattered across three legacy storage formats (ValidatorCatalogEntry, FMU config JSON, template config JSON) into a single relational table.

Key concepts¶

contract_key vs native_name: contract_key is the stable, slug-safe identifier used in CEL expressions, the API, and data path bindings (e.g., panel_area). native_name preserves the provider's original name verbatim (e.g., an FMU's Panel.Area_m2 or an EnergyPlus template variable #{heating_setpoint}). The contract_key is what Validibot uses; the native_name is what the provider uses.

Ownership (XOR constraint): Each definition is owned by exactly one of:

• A Validator — shared step input/output definitions that apply to every step using that validator (library validators).
• A WorkflowStep — per-step definitions for step-level FMU uploads, template scans, or author-customized inputs/outputs.

This is enforced by the ck_sigdef_one_owner database constraint.

Promotion into s.*: When a StepIODefinition is promoted — via its in-row promoted_signal_name (step-owned rows) or a WorkflowStepIOPromotion overlay row (validator-owned rows) — its resolved value is promoted into the s.* (workflow vocabulary) namespace, available in all downstream steps. This works for both directions:

• An OUTPUT-direction definition with promoted_signal_name="simulated_eui" makes its value available as s.simulated_eui after the producing step runs.
• An INPUT-direction definition with promoted_signal_name="zone_count" makes its parsed/resolved value available as s.zone_count from the producing step's input-stage processing onwards — but only in downstream steps, never within the producing step itself (the temporal rule from ADR-2026-05-22b).

This symmetric promotion is the bridge between step-local namespaces (i.*, o.*) and the workflow vocabulary (s.*).

Fields¶

Constraints¶

Two promotion sources: in-row vs. overlay¶

StepIODefinition rows have two ownership patterns, and promotion storage differs accordingly:

Step-owned rows (workflow_step FK set, validator null) — the in-row promoted_signal_name field holds the workflow-scoped promotion name. One owner means no scope ambiguity.

Validator-owned rows (validator FK set, workflow_step null — e.g. the EnergyPlus catalog entries) — these rows are shared across every workflow that uses the validator, so the in-row field can't carry a workflow-scoped name without colliding across workflows. The promotion lives in a separate WorkflowStepIOPromotion overlay table keyed on (workflow_step, signal_definition) so each workflow gets its own promoted name pointing at the same shared catalog row.

The runtime injection in _inject_promotions(), the autocomplete in get_catalog_choices(), the Step Inputs/Outputs tables, the Available Data panel, and the workflow versioning clone all consult both sources — read paths merge them so the overlay is a first-class part of the workflow contract, not a secondary cache.

The overlay model was introduced by the May 2026 P1 fix; before then, Copy-to-Signal on validator-owned catalog rows would 404 because the promote view required a step-owned row.

provider_binding examples¶

FMU signals store causality and value reference:

{
  "causality": "output",
  "value_reference": 42,
  "variability": "continuous"
}

EnergyPlus template signals store variable type and constraints:

{
  "variable_type": "numeric",
  "min": 0,
  "max": 50,
  "choices": null
}

Signal source kinds¶

The source_kind field declares how the signal's value is obtained. This distinction is surfaced in the UI so workflow authors know which signals they can configure and which are fixed by the validator.

PAYLOAD_PATH (default): The signal's value comes from a known data path in the submission payload. The workflow author may (depending on is_path_editable) configure the exact path via the step's signal binding. Most FMU input signals and template signals use this mode — the author wires each input to the right field in their submission data.

INTERNAL: The validator has its own mechanism for extracting or computing the value. Examples include EnergyPlus parser-extracted facts (via extract_input_signals()), EnergyPlus simulation metrics (via extract_output_signals()), THERM signals (parsed inline), and FMU output variables (read from the FMU runtime). The source path in the step binding is typically fixed and should not be changed by the author.

is_path_editable controls whether the source data path field in the signal edit modal is enabled or disabled. When False, Django's field.disabled = True provides server-side protection — even if someone tampers with the form HTML, Django ignores the submitted value.

on_missing behavior on catalog signals¶

The same three-mode semantics as WorkflowSignalMapping.on_missing, but applied per catalog row:

• error — value must be resolvable; run fails with a clear message if not. Use for signals that downstream assertions reliably depend on (e.g. idf_version is required because every IDF has a Version object).
• null (default) — inject null when value can't be resolved. Assertions must guard with has(...) or != null. Surface in the library page as "may be null."
• ignore — omit silently from the context. References resolve to null but don't surface as anything special. Use for genuinely optional facts the author shouldn't need to know about.

Typed metadata accessors¶

StepIODefinition provides typed access to provider-specific metadata through Pydantic accessor properties:

• sig.fmu_binding — FMUProviderBinding (causality, value_reference, etc.)
• sig.fmu_metadata — FMUSignalMetadata (display hints)
• sig.template_metadata — TemplateSignalMetadata (variable type, constraints)

How the two models relate¶

WorkflowSignalMapping and StepIODefinition serve different roles, but they all interact through the same CEL context.

WorkflowSignalMapping                 StepIODefinition (INPUT)
(workflow-level)                      (validator/step-level)

name: "target_eui"                    contract_key: "zone_count"
source_path: "metadata.target_eui"    direction: INPUT
                                      promoted_signal_name: ""
        │                                      │
        ▼                                      ▼
   s.target_eui                          i.zone_count
        │                                      │
        └──────────── CEL ─────────────────────┘
                      │
        i.zone_count >= 4 && s.target_eui < 100


StepIODefinition (INPUT, promoted)    StepIODefinition (OUTPUT, promoted)

contract_key: "zone_count"            contract_key: "site_eui_kwh_m2"
direction: INPUT                      direction: OUTPUT
promoted_signal_name: "zone_count"    promoted_signal_name: "simulated_eui"
        │                                      │
        ▼ promote                              ▼ promote
   i.zone_count                          o.site_eui_kwh_m2
        │                                      │
        └─►  s.zone_count    s.simulated_eui  ◄┘
              (workflow-wide, available downstream)

WorkflowSignalMapping creates signals by extracting values from submission data. Resolved once before any step runs.

StepIODefinition declares the inputs and outputs of individual validators and steps. Either direction can be promoted to the workflow vocabulary by setting promoted_signal_name.

Cross-table signal name uniqueness¶

Signal names must be unique within a workflow across both models. A workflow cannot have a WorkflowSignalMapping named floor_area and a promoted StepIODefinition with promoted_signal_name="floor_area" in the same workflow.

This is enforced at the application level by validate_signal_name_unique() in validibot/validations/services/signal_resolution.py. The function queries both tables:

1. Checks WorkflowSignalMapping.objects.filter(workflow_id=..., name=...)
2. Checks StepIODefinition.objects.filter(workflow_step__workflow_id=..., promoted_signal_name=...) — any direction; with symmetric input promotion, an INPUT-direction promoted_signal_name collides with the same vigour as an OUTPUT-direction one.

Both models call this function in their clean() methods.

Additionally, validate_signal_name() checks that names are valid CEL identifiers and not reserved words. The reserved names list includes all CEL context keys (p, payload, s, signal, i, input, o, output, steps, submission), CEL built-in functions, and CEL keywords. A one-time data migration (workflows/0028_guard_submission_reserved_name) also blocks deploys where a pre-existing signal or promotion was named submission before the name was reserved, with a clear remediation message.

One source of truth: CEL_NAMESPACE_ROOTS¶

The legal namespace roots are defined once, in CEL_NAMESPACE_ROOTS (validibot/validations/cel.py), and every authoring-time allowlist derives from it:

• RESERVED_CEL_NAMES (services/signal_resolution.py)
• _validate_cel_identifiers() and _find_unknown_cel_slugs() (validations/forms.py)
• _validate_cel_expression() (validations/views/rules.py)

The runtime context dict in _build_cel_context() can't derive from a flat set (each root maps to a different value object), so it is locked to the constant by the canary test test_context_root_keys_are_fixed, which asserts the context keys equal CEL_NAMESPACE_ROOTS. Before centralization these lists were hand-copied and had already drifted — the rules view silently omitted i/input — so adding a namespace is now a one-line edit in one place. (row is the one root deliberately not in the constant: it is bound only by the Tabular Validator's row-stage loop and is added contextually by the tabular-aware allowlists.)

Signals vs custom data paths¶

Assertions in Validibot target data in one of two ways.

Declared signals (the data contract)¶

When a validator author defines signals, they are publishing a data contract: "this validator knows about these specific data points." Signals have names (slugs), types, stages (input or output), and metadata. They appear in dropdowns, support type-appropriate operators, and enable compile-time validation of CEL expressions.

This is the structured, guided path. The validator author has done the work of mapping data paths (or parser extraction) to meaningful names, and workflow authors benefit from that investment.

Examples of validators with declared signals:

• EnergyPlus declares output signals for simulation metrics plus input signals for parser-extracted IDF facts
• FMU auto-discovers signals by introspecting the model's variables
• Custom validators where the author manually adds signals through the UI

Custom data paths (no contract)¶

Some validators don't declare signals. The Basic validator, JSON Schema validator, and XML Schema validator validate structure but don't pre-declare what specific fields exist in the data. When a workflow author uses one of these validators and wants to write assertions, they reference data using custom data paths — dot-notation expressions accessed via the p (payload) namespace, like p.building.thermostat.setpoint or p.results[0].value.

This is the flexible, exploratory path. The workflow author navigates the data shape themselves, without the guardrails that declared signals provide.

How the two modes interact¶

The allow_custom_assertion_targets flag on Validator controls whether workflow authors can go beyond declared signals:

When both modes are available, the form shows "Target Signal or Path" and attempts to match user input against signal definitions first, falling back to treating it as a custom path.

Workflow-level signal resolution: resolve_workflow_signals()¶

File: validibot/validations/services/signal_resolution.py

This is the pre-step resolution phase. Before any workflow step executes, all WorkflowSignalMapping rows are resolved against the submission payload. The result is stored in RunContext.workflow_signals and injected into the CEL context as the s / signal namespace.

Resolution algorithm¶

1. Query WorkflowSignalMapping rows for the workflow, ordered by position.
2. For each mapping, call resolve_path(submission_data, mapping.source_path).
3. If the path resolves, store mapping.name -> value.
4. If not found and default_value is set, use the default.
5. If not found and on_missing == "null", inject None.
6. If not found and on_missing == "error", record an error.
7. If any errors accumulated, raise SignalResolutionError.

Where resolution is called¶

StepOrchestrator._resolve_workflow_signals() calls resolve_workflow_signals() before each step execution. The resolved dict is passed via RunContext.workflow_signals to the validator, which injects it into the CEL context.

Step-level input resolution: extract_input_signals() and bindings¶

File: validibot/validations/validators/base/advanced.py (the hook)

Before a step's container runs (or before in-process work for built-in validators), the engine populates i.* from up to three sources:

Parser-extracted facts¶

A validator that understands an arcane format implements extract_input_signals(payload) to expose useful facts about the submission (or about a validator-bound artifact, like the FMU's modelDescription.xml stamped at upload time). Signature:

def extract_input_signals(self, payload: Any) -> dict[str, Any] | None:
    """Extract input-stage facts.

    Returns a dict keyed by catalog contract_key, or None if not
    applicable. Called after preprocess_submission() so template-mode
    submissions are parsed against the resolved IDF.

    Instance method (not classmethod) so subclasses can reach
    self.run_context to look up validator- or step-bound artifacts.
    """

For EnergyPlus, this parses the IDF text and returns {"idf_version": "25.1", "zone_count": 12, "north_axis_deg": 0.0}. For FMU, this reads the stamped FMUModel.introspection_metadata (or step.config["fmu_introspection"] for step-level uploads) and returns {"fmi_version": "2.0", "input_variable_count": 4, ...} — filtered to the catalog-declared parser fact keys so the catalog stays the contract.

The base class returns None; validators opt in by overriding.

Resolved StepInputBindings¶

For each StepIODefinition with direction=INPUT that has a corresponding StepInputBinding row, the launcher resolves the binding's source_data_path against the submission data. The resolved value lands in i.<contract_key>.

For FMU steps, this is how the per-submission model input variables get into i.*. For EnergyPlus template steps, this is how the template variable values get into i.*.

Catalog defaults¶

For declared inputs without parser values or resolved bindings, the catalog's on_missing policy applies:

• error → run fails with a clear message before the container starts
• null → injected as None
• ignore → omitted from the dict (references resolve to null)

Persistence¶

Resolved i.* values are persisted to the run summary under run.summary["steps"][step_key]["input"] so they're available to downstream steps via steps.<key>.input.*.

Promoted signals reconstruction: _inject_promotions()¶

File: validibot/validations/validators/base/base.py

When a StepIODefinition (any direction) is promoted — in-row promoted_signal_name for step-owned rows, WorkflowStepIOPromotion overlay row for validator-owned rows — the resolved value is "promoted" into the s.* namespace for downstream steps. The method handles inputs and outputs uniformly (it originally handled only outputs).

How it works¶

1. _inject_promotions() runs inside _build_cel_context() when the steps context is non-empty (i.e., there are completed upstream steps).
2. It gathers promotions across all upstream steps in the current workflow (filtered by workflow_step__order__lt=current_step.order to enforce the temporal rule — a step cannot see its own promotion), merging in-row promoted_signal_name rows with WorkflowStepIOPromotion overlay rows.
3. For each promoted definition, it looks up the producing step's step_key in the steps context.
4. It extracts the value using the definition's contract_key:
5. For OUTPUT-direction promotions: from step["output"][contract_key]
6. For INPUT-direction promotions: from step["input"][contract_key]
7. If found, it injects the value into signals_dict under the promoted_signal_name.

Why it runs on every step¶

Promoted values are only available after the producing step completes. Since different steps may complete at different times (especially with async validators), _inject_promotions() runs fresh on every step rather than once at the start of the run.

Example¶

Given a StepIODefinition for input promotion:

• contract_key = "zone_count", direction = INPUT, promoted_signal_name = "zone_count", on step with step_key = "preflight"

And a run summary:

{"steps": {"preflight": {"input": {"zone_count": 12}}}}

The promotion injects signals_dict["zone_count"] = 12, making it accessible as s.zone_count in downstream CEL expressions.

The same mechanism works for OUTPUT-direction promotions reading from step["output"][contract_key].

How signals are defined¶

Config-based definition (advanced validators)¶

Advanced validators define their step inputs/outputs in config.py modules co-located with the validator code. Each config module exports a ValidatorConfig instance containing a list of CatalogEntrySpec objects that seed StepIODefinition rows. Each CatalogEntrySpec can declare source_kind, is_path_editable, and on_missing to control how the value is obtained and what happens when it can't be resolved.

Key files:

• validibot/validations/validators/base/config.py — CatalogEntrySpec and ValidatorConfig Pydantic models
• validibot/validations/validators/energyplus/config.py — EnergyPlus signal definitions
• validibot/validations/validators/fmu/config.py — FMU config (empty catalog_entries; signals created dynamically via introspection)

Dynamic definition (FMU validators)¶

FMU validators don't predefine signals in config. Instead, when an FMU file is uploaded, sync_fmu_catalog() in validibot/validations/services/fmu.py introspects the FMU's modelDescription.xml, discovers all input/output variables, and creates StepIODefinition rows dynamically.

Each FMU variable's causality (input, output, parameter) determines whether it becomes an INPUT or OUTPUT signal. The contract_key is derived from the variable name via slugify(), and the native_name preserves the original FMU variable name.

Custom validators¶

Users can add signals to custom validators through the UI. The signal definition forms handle creation and editing.

Syncing configs to the database¶

The sync_validators management command (validibot/validations/management/commands/sync_validators.py) discovers all ValidatorConfig instances via discover_configs() and upserts Validator + StepIODefinition rows.

python manage.py sync_validators

How signals flow during execution¶

Complete lifecycle¶

1. DEFINITION                     config.py, FMU introspection, or UI
   ├─ StepIODefinition            Django model rows (validator or step owned)
   └─ WorkflowSignalMapping       Django model rows (workflow-level)

2. WORKFLOW RUN STARTS            StepOrchestrator.execute_workflow_steps()
   ├─ resolve_workflow_signals()  Resolve WorkflowSignalMapping → s namespace
   └─ _extract_downstream_signals() Collect prior step inputs/outputs → steps namespace

3. EACH STEP EXECUTES             validate() + post_execute_validate()

   3a. INPUT STAGE
       ├─ preprocess_submission() Template-mode IDF substitution
       ├─ extract_input_signals() Parse facts from (resolved) payload → i namespace
       ├─ Resolve StepInputBindings    → i namespace
       ├─ store input dict to run summary
       ├─ _build_cel_context(stage="input")
       │     p, s, i, steps namespaces populated; o is empty
       ├─ _inject_promotions()   Promotions visible from completed upstreams
       └─ Evaluate input-stage assertions

   3b. EXECUTION
       └─ Container or in-process work runs

   3c. OUTPUT STAGE
       ├─ extract_output_signals()  → o namespace
       ├─ store output dict to run summary
       ├─ _build_cel_context(stage="output")
       │     all namespaces populated
       ├─ _inject_promotions()
       └─ Evaluate output-stage assertions

4. RUN SUMMARY STORAGE
   ├─ run.summary["steps"][step_key]["input"] = i dict
   └─ run.summary["steps"][step_key]["output"] = o dict
     Both available downstream as steps.<step_key>.input.* / .output.*

Within a single step¶

1. Preprocessing. For EnergyPlus template mode, preprocess_submission() substitutes template variables into the IDF so the submission looks like a direct-IDF upload by the time the parser runs. For other validators, this is a no-op.

2. Input population. extract_input_signals() parses the payload (if the validator implements it). Resolved StepInputBindings are collected. The merged dict becomes i.*.

3. Input persistence. The i.* dict is stored to the run summary under run.summary["steps"][step_key]["input"] so downstream steps can reach it.

4. CEL context building (input stage). _build_cel_context() assembles the namespaces: p/payload (raw data), s/signal (workflow signals + promoted values), i/input (this step's inputs), o/output (empty at input stage), and steps (upstream step inputs and outputs).

5. Input-stage assertion evaluation. CEL expressions reference signals via s.* and step-local inputs via i.*. The assertion form has already ensured no expression references o.* at this stage.

6. Validator execution. The validator runs (container launch, in-process check, AI call, etc.).

7. Output extraction. The validator returns extracted outputs. For advanced validators, extract_output_signals() converts the container output envelope into a flat dict.

8. Output-stage assertion evaluation. CEL expressions reference output values via o.* and may freely reference any other namespace.

9. Output persistence. The o.* dict is stored to the run summary under run.summary["steps"][step_key]["output"].

Across steps (cross-step communication)¶

Inputs and outputs from earlier steps are available to later steps in the same run:

1. Storage. When step N completes, both its inputs and outputs are saved to validation_run.summary:

{
  "steps": {
    "preflight": {
      "input": {"idf_version": "25.1", "zone_count": 12},
      "output": {"warning_count": 3, "fatal_count": 0}
    },
    "energyplus_step": {
      "input": {"idf_version": "25.1", "zone_count": 12, "north_axis_deg": 0.0},
      "output": {"site_eui_kwh_m2": 87.5, "site_electricity_kwh": 12500}
    }
  }
}

1. Collection. Before step N+1 runs, StepOrchestrator._extract_downstream_signals() reads the summary and collects inputs and outputs from all prior steps.

2. Context injection. The collected data is passed to the validator via RunContext.downstream_signals, then exposed in the CEL context under the steps namespace:

steps.energyplus_step.output.site_eui_kwh_m2
steps.preflight.input.zone_count

1. Promoted values. If any upstream step has a promoted StepIODefinition (in-row name or overlay row), _inject_promotions() places the value into the s.* namespace:

s.simulated_eui < s.target_eui     # if upstream output promoted
s.zone_count >= 4                  # if upstream input promoted

This lets a downstream step write assertions that reference upstream data either by the full path (steps.<key>.input.* or steps.<key>.output.*) or by promoted signal name (s.<signal_name>).

CEL context building in detail¶

The _build_cel_context() method on BaseValidator (validibot/validations/validators/base/base.py) is the heart of the context assembly. It builds the dictionary that CEL expressions evaluate against.

Signature:

def _build_cel_context(
    self,
    payload: Any,
    validator: Validator,
    *,
    stage: str = "input",
) -> dict[str, Any]

What it does:

1. Builds the s (signals) namespace from two sources:
2. Workflow-level signals from RunContext.workflow_signals

3. Promoted values from upstream steps via _inject_promotions()

4. Builds the i (inputs) namespace from three sources:

5. Parser-extracted facts via the validator's extract_input_signals() (if implemented)
6. Resolved StepInputBinding values

7. Catalog defaults for declared inputs without resolved values

8. Builds the o (outputs) namespace. At the output stage, the full validator output payload is used. At the input stage, o.* is empty (or null-defaulted) — the container hasn't run.

9. Builds the steps namespace from RunContext.downstream_signals or the run summary, including both input and output sub-dicts per completed step.

10. Assembles the final context with all namespace keys: p, payload, s, signal, i, input, o, output, steps. All roots are always present (even if empty) so CEL expressions can reference them without undefined-variable errors.

Output signal elevation pipeline¶

Output signals from advanced validators (FMU, EnergyPlus) go through a multi-stage pipeline before they become CEL variables.

Stage 1: Extraction — extract_output_signals()¶

Each advanced validator class defines an extract_output_signals() classmethod that converts the container's output envelope into a flat Python dict of signal names to values. For FMU validators, this dict contains the final time-step values of each output variable:

# FMU extract_output_signals() returns:
{"T_room": 296.63, "Q_cooling_actual": 5172.83}

This method is called in AdvancedValidator.post_execute_validate() after the container completes. The extracted dict is stored in ValidationResult.signals and later persisted to run.summary by the processor's store_signals() method.

Stage 2: Payload merging¶

Before output-stage assertions are evaluated, the validator output is placed in the o / output namespace.

Stage 3: CEL context building¶

_build_cel_context(stage="output") places the output dict in o.*, keeps i.* populated from input-stage resolution, refreshes s.* with any newly-promoted signals, and exposes upstream data via steps.*.

Stage 4: CEL evaluation¶

When cel-python compiles the expression o.T_room < 300.15, it parses the dot as member access — the standard CEL operator for selecting a field from a map. At evaluation time:

1. CEL looks up the variable o in the activation context
2. Finds the Python dict {"T_room": 296.63, ...}
3. cel-python's json_to_cel() converts the dict to a CEL MapType
4. The .T_room selector retrieves the value 296.63 from the map
5. The comparison 296.63 < 300.15 evaluates to true

Standard CEL — no custom operators, no dialect extensions.

Signal extraction for advanced validators¶

EnergyPlus input extraction (parser facts)¶

File: validibot/validations/validators/energyplus/validator.py

@classmethod
def extract_input_signals(cls, payload: Any) -> dict[str, Any] | None:
    """Parse the (resolved) IDF text and extract declared input facts.

    Returns a dict like {"idf_version": "25.1", "zone_count": 12, ...}
    keyed by catalog contract_key.
    """

Runs after preprocess_submission() so template-mode submissions are parsed against the resolved IDF, not the unresolved JSON variable dict.

EnergyPlus output extraction (simulation metrics)¶

File: validibot/validations/validators/energyplus/validator.py

@classmethod
def extract_output_signals(cls, output_envelope: Any) -> dict[str, Any] | None:
    metrics = output_envelope.outputs.metrics
    if hasattr(metrics, "model_dump"):
        metrics_dict = metrics.model_dump(mode="json")
        return {k: v for k, v in metrics_dict.items() if v is not None}

The EnergyPlusSimulationMetrics Pydantic model (from validibot-shared) defines all possible output fields. model_dump() converts them to a dict, and None values are filtered out.

Not every signal will be populated for every IDF. The signal definitions declare the full set of metrics that the validator knows how to extract, but EnergyPlus only produces a value when the IDF is configured to generate it. When a signal is absent from the extracted dict, the display layer reports "Value not found" and the on_missing policy on the catalog row determines runtime behaviour.

FMU input resolution¶

File: validibot/validations/services/cloud_run/launcher.py

Before launching an FMU container, the launcher resolves input signals from the submission payload using StepIODefinition rows with direction=INPUT. Resolved values land in i.* for input-stage assertions to reference.

Storage¶

Signals are not stored in a dedicated table. They live in the summary JSONField on ValidationRun, nested under steps.<step_key>.input and steps.<step_key>.output. This keeps signal storage lightweight (no extra rows per signal per run) and naturally scoped to the run lifecycle.

The store_signals() method on ValidationStepProcessor (validibot/validations/services/step_processor/base.py) handles persistence:

def store_signals(
    self,
    signals: dict[str, Any],
    *,
    stage: str,
) -> None:
    if not signals:
        return
    summary = self.validation_run.summary or {}
    steps = summary.setdefault("steps", {})
    step_key = self.step_run.workflow_step.step_key or str(self.step_run.id)
    step_data = steps.setdefault(step_key, {})
    step_data[stage] = signals  # stage is "input" or "output"
    self.validation_run.summary = summary
    self.validation_run.save(update_fields=["summary"])

The _extract_downstream_signals() method on StepOrchestrator (validibot/validations/services/step_orchestrator.py) reads these stored values back for downstream steps, structuring them as {step_key: {"input": {...}, "output": {...}}}.

Path resolution¶

The resolve_path() function in validibot/validations/services/path_resolution.py handles dotted and bracket notation for navigating nested dict/list payloads. Both _build_cel_context() and resolve_workflow_signals() use this shared function.

Supported syntax:

• Dotted paths: building.envelope.wall.u_value
• Bracket notation: results[0].temp
• Mixed: building.floors[0].zones[1].sensors[2]

Key function reference¶

Related documentation¶

• Signals Tutorial Example — End-to-end worked example
• Validators — Catalog model and seed data
• Assertions — How signals, step inputs, and step outputs are referenced in rules
• Step Processor — Step input/output extraction and storage implementation
• Workflow Engine — Value flow through workflow execution
• Results — How values appear in run summaries
• CEL Expressions (user-facing) — Author-oriented namespace reference
• ADR-2026-05-22 — EnergyPlus catalog cleanup and the i.* namespace (internal)
• ADR-2026-05-22b — Terminology (signal vs. step input/output) and model rename (internal)

Appendix: code-vs-vocabulary¶

The vocabulary used throughout this doc — signal, step input, step output, promotion — matches the user-facing UI and the public documentation. The Python class identifiers were aligned with this vocabulary in May 2026 per ADR-2026-05-22b (internal). The underlying database table names and a handful of URL slugs were intentionally left alone to avoid a destructive rename on mature data and to avoid churning every workflow link in the codebase.

The runtime injection method is _inject_promotions — it handles both in-row and overlay promotions, for inputs and outputs alike. (Earlier revisions called it _inject_promoted_outputs; if you see that name in older ADRs or commit messages, it's the same mechanism.)
